Mo 9

The Mo 9 has been in use for various football productions since its completion. It was created in close collaboration with our customer within a very short time. From the first drawing to the start of production only six months of construction time were necessary.

The 45m² large editorial and production vehicle has, among other things, two extendable compartments, a transitable roof, network technology and a large seating area for meetings. An 8x8 HDMI matrix and the possibility to connect a satellite dish to the mobile, supplies all office space with the desired image material.

Alternatively, the external connection panel and the built-in BNC connections (SDI-HD-SDI) allow image transmission from the OB vehicle on site.

Highlights

Possible equipment options

We are happy to adapt the space layout and equipment and the number of office cabinets or desks to your wishes and different production projects. Roof terrace only available as a special request - other special features on request.

  • Up to 8 workstations
  • Fridge
  • Air conditioning
  • Heating
  • Telephone/fax
  • Fully automatic coffee machine
  • Copiers
  • Make-up mirror
  • Built-in kitchen
  • Meeting room with sitting area
  • BNC connection lines
  • Network cabling
  • External connection field
  • Satellite dish
  • 8 x 8 HDMI-Matrix

References

  • 1st Bundesliga
  • Sky Top game of the week
  • Champions League
  • various promotional advertising shoots, among others Effes Bundesliga check for Sky

Download

Mo 9 - Vehicle sketch (PDF)

Vehicle data

Length (truck and semi-trailer): 16,40m
Length (only semi-trailer): 13,50m
Width: 2,50m
Width (extended compartments): 3,50m
Height: 3,95m
Weight (semi-trailer): 19.300kg
Weight (truck): 7.700kg
Power requirement: 2x32CEE

Vehicle sketch

Mo 9 - Vehicle sketch

Gallery
